What is PWM2?

Last Updated on2020-07-31 08:30:52
What is PWM2?
PWM2 is a PWM mode that applies to an STM32 timer. In up-counting, channel 1 is inactive as long as TIMx_CNT is less than TIMx_CCR1; otherwise it is active. In down-counting, channel 1 is active as long as TIMx_CNT is greater than TIMx_CCR1; otherwise it is inactive.
